Telescopic work platform 22.5m
GT 225-24 AkPR GT 225-24 AkPR
22,56 m Max. Working height
450 kg Max. Basket load / Lifting load
Diesel Drive type
Price on request
| Max. Working height | 22,56 m |
| Movable up to working height | 22,56 m |
| Max. Platform height | 20,56 m |
| Max. lateral reach | 18,79 m |
| Max. Basket load / Lifting load | 450 kg |
| Max. Pitch angle | 40° ° |
| Four-wheel drive | yes |
| Drive type | Diesel |
| Non-Marking | no |
| Overall dimensions LxWxH | 10.46 x 2.46 x 2.67 m |
| Transport position length | 7,37 m |
| Construction width | 2,46 m |
| Transport position height | 2,67 m |
| Ground clearance | 0,31 m |
| Surplus | 1,10 m |
| Dead weight | 13320 kg |
| Track widening | – |
| Platform dimensions WxD | 2.44 x 0.92 m m |
| Swing axle | yes |
| Basket arm | yes |
| Swivel range | 360° |
| Rotating work basket | yes |
| Special features | High basket load |
Technical specifications, prices and images are subject to change.
