Telescopic work platform 15.7m
GT 157-25 AkP GT 157-25 AkP
15,96 m Max. Working height
454 kg Max. Basket load / Lifting load
Diesel Drive type
Price on request
| Max. Working height | 15,96 m |
| Movable up to working height | 15,69 m |
| Max. Platform height | 13,69 m |
| Max. lateral reach | 11,97 m |
| Max. Basket load / Lifting load | 454 kg |
| Max. Pitch angle | 45% ° |
| Four-wheel drive | yes |
| Drive type | Diesel |
| Non-Marking | yes |
| Overall dimensions LxWxH | 9.15 x 2.49 x 2.52 m |
| Transport position length | 7,45 m |
| Construction width | 2,49 m |
| Transport position height | 2,72 m |
| Ground clearance | 0,33 m |
| Surplus | 0,97 m |
| Dead weight | 7121 kg |
| Track widening | - |
| Platform dimensions WxD | 2.44 x 0.92 m m |
| Swing axle | yes |
| Basket arm | yes |
| Swivel range | 360° |
| Rotating work basket | yes |
| Special features | Extremely high basket load, can be used up to max. 7° inclined position, optionally available with 4 m basket (change of basket load to 272 kg), Genie® Lift Guard™ shut-off bar |
