GH 143
GH 143
Support dimension LxW2.05 x 2.25 m
Drive type230 V
Extendable work basket–
Daily price218,96 €Graduated prices / incl. VAT.
Freitagsrabatt 40%
Secure online payment:
Certified by Trusted Shops!
Data sheet
| Support dimension LxW | 2.05 x 2.25 m |
|---|---|
| Drive type | 230 V |
| Extendable work basket | – |
| Construction width | 0,74 m |
| Ground clearance | 0,04 m |
| Corner access | 0,79 m |
| Dead weight | 547 kg |
| Shunting drive | no |
| Transport position height | 1,98 m |
| LxWxH tilted | 2.87 x 0.74 x 1.96 m |
| Overall dimensions LxWxH | 1.42 x 0.74 x 2.83 m |
| Transport position length | 1,42 m |
| Max. Working height | 14,32 m |
| Max. Basket load / Lifting load | 136 kg |
| Indoor use only | no |
| Platform dimensions WxD | 0.66 x 0.68 m |
| Max. Platform height | 12,32 m |
| Support pressure max. | 1.8 kN |
| Supports | ja |
| Wall clearance front side | 0,38/0,71 m |
| Rotatable basket | no |
