GL 16 K
| Max. Working height | 16,35 m |
|---|---|
| Max. lateral reach | 9,90 m |
| Max. Basket load / Lifting load | 200 kg |
| Platform dimensions LxW | 1,20 x 0,70 m |
| Overall dimensions LxWxH | 6.78 x 2.12 x 2.80 m |
| Support length | 3,28 m |
| Support width on both sides | m |
| Support width on one side | - |
| Vertical support width | 2,17 |
| Dead weight | 3350 kg |
| Perm. total weight | 3500 kg |
| Drive type | Diesel |
| Four-wheel drive | no |
| Ground clearance | 0,20 m |
| Rotating work basket | ja |
| Swivel range | 2 x 175° |
| Basket arm | no |
| Driving licence | B / 3 |
| Special features | Compact design, loading area with drop sides, box body for material 1.50 x 0.50 x 0.50 m / open workman basket, rotating workman basket |
