GH 083
GH 083
Support dimension LxW1.52 x 0.81 m
Drive type230 V
Extendable work basket-
Daily price115,43 €Graduated prices / incl. VAT.
Freitagsrabatt 40%
Secure online payment:
Certified by Trusted Shops!
Data sheet
Support dimension LxW | 1.52 x 0.81 m |
---|---|
Drive type | 230 V |
Extendable work basket | - |
Construction width | 0,81 m |
Ground clearance | 0,05 m |
Corner access | 0,15 m |
Dead weight | 611 kg |
Shunting drive | no |
Transport position height | 1,93 m |
Overall dimensions LxWxH | 1.52 x 0.81 x 1.93 m |
Transport position length | 1,52 m |
Max. Working height | 8,30 m |
Max. Basket load / Lifting load | 159 kg |
Indoor use only | no |
Platform dimensions WxD | 0.66 x 0.69 m |
Max. Platform height | 6,30 m |
Support pressure max. | 4 kN |
Supports | ja |
Wall clearance front side | 0 m |
Special features | Very compact device dimensions in working position |
Rotatable basket | no |
