GA 25 J
Max. Working height24,98 m
Max. Basket load / Lifting load200 kg
Construction width1,65 m
Price on request
Secure online payment:
PayPal
Invoice
Certified by Trusted Shops!
Data sheet
|
Max. Working height
|
24,98 m |
|---|---|
|
Max. lateral reach
|
10,53 m |
|
Max. Basket load / Lifting load
|
200 kg |
|
Overall dimensions LxWxH
|
9.13 x 1.65 x 2.10 m |
|
Transport position length
|
9,13 m |
|
Construction width
|
1,65 m |
|
Transport position height
|
2,10 m |
|
Drive type
|
230 V |
|
Dead weight
|
2450 kg |
|
Max. Platform height
|
22,98 m |
|
Platform dimensions LxW
|
1,17 x 0,68 m |
|
Supports
|
ja |
|
Support pressure max.
|
18 kN |
|
Support width on both sides
|
5,66 m |
|
Support length
|
5,64 m |
|
Ground clearance
|
0,26 m |
|
Rotating work basket
|
ja |
|
Basket arm, rotation angle
|
no90° |
|
Indoor use only
|
no |
|
Shunting drive
|
ja |
|
Swivel range
|
endless |
|
Special features
|
Low tare weight |
